  • Warm White, BA15S Bayonet, Dimmable, Waterproof cover, Omni, 360 degree illumination
  • BA15S, 3000K warm white, 12V AC/DC, 4W, 350-400LM
  • 35 x Longer life time compared with traditional Incandescent bulbs, plus less heat output and extremely low power consumption
  • Direct replacement for BA15S base, single filament, 1156 Series also known as: 3497, 1073, 1141, 7506, 1093, 1159, 1295, 7527 (For Reference Only)
  • No UV or IR radiation, low heat
  • BA15S base (Single Contact In-line Bayonet), diameter 0.59” 15.2mm
  • Size: 1.95” (49.6mm) total length, Max Diameter 0.69” (17.6mm)
  • Life: 50,000 hours
  • 2 year warranty
Bulb Type
BA15
Voltage / Power
Input Voltage 12V AC/DC
Constant Current / Voltage Constant Voltage
Wattage 4W
General
Lumens 400
Bulb Color Warm White
Bulb Included Yes
Color Temperature K 3000K
LED Qty 45
Dimmable Yes
IP Rated IP65 No Dust / Water Jets
submersible No
Wiring (Series / Parallel) Parallel
Location Indoor/Outdoor
Angle 360
Dimensions
Length 1.95"
Diameter 0.69"
Warranty
2 yr.
Life (hrs) 30000

Waterproof LED BA15S (Eq. to 40W Halogen) Dimmable 12V AC / DC

  • Brand: illuminous
  • Product Code: EV-LED-BA15S-4W-DIM
  • Availability: In Stock
  • $2.99
